STATIONARY COMPLEXES WITH ELECTRON ACCELERATORS

Ionizing radiation complexes to treat agricultural products and much more

The STATIONARY COMPLEX is unique as it is a ready-to-install set of 4 modules for quick installion directly on site - phytosanitary treatment centers, in logistic centers, storage terminals, sterilization centers, medical production facilities, ports, airports, etc.

QUICK INSTALLATION - QUICK STARTUP

MODULE 1. RADIATION MODULE:
Electron Accelerator
Casing is the radiation shield foundation which is filled with concrete/metal
Built-in Conveyor System

AUXILIARY MODULES:
MODULE 2. ELECTRONICS
MODULE 3. COOLING AND OZONE EXHAUST SYSTEMS
MODULE 4. CONTROL ROOM

RADIATION MODULES
TREATMENT THROUGH WALLS OF CARGO CONTAINERS

  • The electron accelerator installed in the module has a power of 100 kW and an energy of 5 or 7 MeV
  • Mode: X-Ray
RC-CARGO
TREATMENT OF PALLETIZED PRODUCTS

  • The electron accelerator installed in the module has a power of 50 kW to 100 kW and an energy of 5 MeV
  • Mode: X-Ray
    RC-P
    TREATMENT OF BOXED PRODUCTS

    • The electron accelerator installed in the module has a power of 50 kW to 100 kW and an energy of 5 MeV
    • Mode: X-Ray and E-Beam
      RC-B
      TREATMENT OF BULK PRODUCTS

      • The electron accelerator installed in the module has a power of 50 kW to 100 kW and an energy of 5 MeV
      • Mode: E-beam
      RC-BOL
      DRINKING WATER DISINFECTION
        • The electron accelerator installed in the module has a power of 50 kW to 100 kW and an energy of 5 MeV
        • Mode: E-beam
        RC-LIQUIDS
        WASTEWATER TREATMENT

        • The electron accelerator installed in the module has a power of 50 kW to 100 kW and an energy of 5 MeV
        • Mode: E-beam
          RC-LIQUIDS
          RADIATION MODULE
          Electron Accelerator
          ELECTRON ACCELERATOR

          · Energy: 1 to 7 meV
          · Power: 20 to 100 kW
          · Mode of Operation: e-Beam and X-ray
          · Transition Period for Mode Switching: 3 min
          Similar to the biological radiation protection in nuclear submarines
          RADIATION SHIELD

          Can be filled with concrete or metal crumb.

          The unique design of complex's local radiation protection is similar to the biological radiation protection used in nuclear submarines.

          Dimensions:
          Maximum dimensions for concrete: 17*8 m
          Minimum dimensions for metal: 4*3 m
          BUILT-IN CONVEYOR SYSTEM

          The radiation module is equipped with various conveyors, piping and other systems for supplying various products, materials and substances to the irradiation zone.

          The conveyor system is made-to-order based on the following customer requirements:

          - Types of products to be processed
          - Processing method (in boxes/bags, on pallets, in bulk)
          - Maximum dimensions of packaging with products
          - Thickness and density of the packaging material
          - Production capacity kg/h
          Conveyor
          Piping for Waste Water
          System for Polymer Crosslinking
          AUXILIARY MODULES


          ELECTRONICS AND COOLING SYSTEM MODULES

          Container dimension: 20'

          CONTROL ROOM MODULE


          INSTALLATION OF RADIATION MODULES
          The radiation module may be installed as shown
          Option 1 - inside the production facility or
          Option 2 - in a finished goods stock / in a separate compartment next to the production floor
          PRODUCT PROCESSING OPTIONS
          • Treatment in a bulk in one layer
          • Treatment in boxes
          • Treatment on pallets
          • Treatment in cargo containers
          ADVANTAGES FOR ENTERPRISES
          Independence
          • The complex can be operated at any time at your production area
          • The company does not depend on the third parties that previously sterilized products
          • The complex operates from the electrical grid and use electricity only at the time of product sterilization
          Quality assurance
          • Self-monitoring of sterilization process
          • Guaranteed compliance of exported products with phytosanitary control and other requirements
          Income growth
          • Dramatically increased safety and shelf life of products
          • Greater potential to enter new markets
          • More opportunities for expanding the production lines
          • Opportunity to render services to third parties
          Decreased expenses
          • No transportation costs related to sending the products to sterilization centers
          • The cooling system of the electron accelerator can be used as a heating system for the room
          • The complex can be used at night time at reduced electricity tariff
          • Prevention of financial losses as there are no claims on product sterility
          Consumer trust
            • Consumers will choose your product because they will be confident in its quality
            Easy Implementation
            • The complex is a ready-to-use product for easy and quick installation
            • The complex can be connected to the existing conveyor system
            • Installation does not require additional construction and temporary shutdown of production
            • The complex can be easily moved to another facility if needed

              PRODUCTIVITY AND ENERGY CONSUMPTION

              Products thickness of 50 mm - eBeam processing
              Products thinkness of 50+ mm – X-ray processing
              *products thinkness of 50 mm was taken into account for product density of 1 gram per cubic cm.
              For products density in a pack of 0.25 gram per cubic cm, the products thinkness can be 200 mm for eBeam processing.

              APPLICATIONS
              IMPLEMENTED PROJECTS - X-RAY/E-BEAM CENTERS
              Our company also specializes in construction of multifunctional ionizing radiation centers with electron accelerators to process various types of products.
              IMPLEMENTED PROJECTS - COMPLEXES
              Functional test for system prior to shipping
              STATIONARY COMPLEXES AND CENTERS
