Universal Irradiation Module

Module is equipped with

Electron accelerator: energy 5 MeV, power from 50 kW to 100 kW, operates in E-beam and X-ray modes, the time it takes to change the electron beam to X-ray mode is 20 minutes

Radiation shield: in the production of module, it is possible to use various materials depending on the area of accommodation and customer requirements. Types of radiation protection materials: concrete, metal and others.

Ozone exhaust system: there are two possible options for removal of ozone: 1. an exhaust system into the atmosphere where it will decompose within minutes, and 2. ozone decomposition process with catalysts.

Accelerator emergency shutdown system: triggered in case of emergency situations in which the electron accelerator is switched off in automatic as well as manual modes

Integrated conveyor system: conveyor speed adjustable from 1 to 1500mm / s
  • Possibility of the conveyor integration with existing systems of the enterprise
  • Possibility of installing a conveyor with a flipping option

Fire extinguishing system:
triggered in case of emergency in which the electron accelerator is turned off and the fire extinguishing system is turned on in automatic as well as manual modes

Control system: dosimetry, conveyor speed control, electron accelerator control, fire extinguishing, cooling, ventilation and emergency shutdown of the accelerator

Technical specification

Module dimensions: 12m x 4m x 5.5m (metal shield); 17m x 7.5m x 6.5m (concrete shielding)
Power Supply: 300kW
Power consumption: 250kw per hour
Voltage: 380V
Current Frequency: 50Hz
Maximum dimensions of packaging for treated products: 1100 mm x 600 mm x 500 mm
