MULTIFUNCTIONAL PREFABRICATED COMPLEXES WITH ELECTRON ACCELERATORS

EQUIPMENT FOR STRATIGIC FOOD RESERVE STOCKS

BEAMCOMPLEX manufactures multifunctional complexes with electron accelerators and other special equipment to treat agricultural products and much more

Configuration

The equipment is produced in containers. Such complex is a plug and play installation.
As it is a ready-to-install equipment, the use of such a complex reduces commissioning period and cost of a facility.

The complex has 4 MODULES (40ft containers):

MODULE 1 (radiation module) consists of:
- Electron Accelerator (1 to 5 MeV, 20 to 100 kW).
Operation mode: E-beam/X-Ray
- Special equipment
- Module casing (filled with concrete at the site of installation).

MODULE 2 - Electronics
MODULE 3 - Accelerator's cooling and ventilation systems
MODULE 4 - Control room of complex

7 BENEFITS OF HAVING SUCH COMPLEX

The compact complex can be located directly in the production shop or in a separate building next to the finished product area.

The complex may be installed without plant shutdown.

The complex may be connected to the existing manufacturing lines of the plant.

No transportation costs for product irradiation at third party companies.

No risk of violation of temperature regime and damage of product integrity during transportation and handling operations for product irradiation at third party companies.

Full independent control of product irradiation.

Your company may render irradiation services to third parties and increase your income.

The complexes are built to order and equipped with special equipment and electron accelerators considering a type of products to be processed.

Special equipment:

radiation module casings
conveyor systems
packaging lines
neutral gas supply system
product cooling system
product rotation system
speed control system for conveying products into the irradiation zone
radiation monitoring system
other required equipment

DETAILED INFORMATION ON TECHNICAL PARAMETERS OF SPECIAL EQUIPMENT IS PROVIDED FOR EACH REQUEST FOR PRODUCTION OF THE COMPLEX AFTER AGREEING THE PARAMETERS OF THE PRODUCTS TO BE PROCESSED.

ELECTRON ACCELERATORS - MAIN ELEMENT OF MULTIFUNCTIONAL COMPLEX

RADIATION MODULES

Our company manufactures 2 types of radiation modules:

Module as a casing for concrete bunker
Module as a metal radiation shield

CONVEYOR SYSTEMS

The complexes can be simultaneously equipped with 2 to 3 conveyor systems to irradiate products in boxes, in bulk in one layer, on pallets, in bags and in cargo containers.

Conveyor System for Water

Conveyor System for Pallets

Conveyor System for Boxes

Conveyor System for Boxes & Pallets

Conveyor System for Products in Bulk

Two-way Treatment System

Boxes on Conveyor

Conveyor for 40ft Containers

FACILITY CONSTRUCTION STEPS

1

Quick installation of the modules on a prepared area inside a facility.
2

Installing a formwork around the radiation module and filling it with concrete.
3

Сonnection of all systems of the 4 modules to each other.
4

Connection to an external cooling systems (chillers).
5

Connection of an ozone exhaust system to an exhaust system outside the facility perimeter.
6

Connection of the complex to the power supply and commissioning.
